Base Plate Round suits 50mm 2″ Tube Satin Finish ProRail AISI 316
Product Code: E5251-50SF
Brand: Econ
$14.32 ex.GST
To access Trade Prices, click below
TRADE FORM
Base Plate suits 2" (50mm) Tube Satin Finish Econ AISI 316
Miami Stainless Econ Base Plates are high quality AISI 316 marine grade stainless steel available in both satin finish and mirror polish. Econ Base Plates are easy to install, suit Australian standard size tube and are available with a larger internal hole to allow passage over inserted 6.0mm Splined Blind Nut Rivets.
Base Plate Suits Tube AISI 316
Technical Drawing
Specifications
| Code | Wt | D1 | D2 | D3 | D4 |
|---|---|---|---|---|---|
| E5251-25* | 135g | 70 | 30 | 51 | 8 |
| E5251-50SF | 275g | 102 | 51 | 70 | 8 |
| E5251-50MP | 275g | 102 | 51 | 70 | 8 |
Please specify Mirror Polish or Satin Finish (only available in 50mm) when ordering. *Mirror Polish
