Eye Nut Screw Eye 10mm x 80mm Econ AISI 316

Product Code: S3291-10080EC

Brand: Econ

$3.99 ^ex.GST

To access Trade Prices, click below

TRADE FORM

Eye Nut Coach Screws 10mm x 80mm AISI 316

Miami Stainless cast Econ AISI 316 stainless steel eye screw nuts are specifically designed to fasten into wooden posts, walls or panels for lifting purposes. Miami Stainless eye screw nuts can also be used to fasten stainless steel fittings to stair, ramp or angled sections.

CODE	SIZE	D	L	A	H	D1	PULL OUT*
S3291-05060 - PRORIG	5X60	5	60	11	5	20	550
S3291-06060 - PRORIG	5X60	6	60	14	6	26	550
S3291-06060 - ECON	5X60	6	60	14	6	26	550
S3291-08080 - PRORIG	8X80	8	80	18	8	33	820
S3291-08080 - ECON	8X80	8	80	18	8	33	820
S3291-10080 - PRORIG	10X80	10	80	22	10	41	645
S3291-10080 - ECON	10X80	10	80	22	10	41	645
S3291-12100 - PRORIG	12X100	12	100	27	12	50	1625
S3291-12140 - PRORIG	12X140	12	140	27	12	50	1660
S3291-12160 - PRORIG	12X160	12	160	27	12	50	1830
