Wire Rope Grip 'Q' - ALL SIZES

S260Q-03

Wire Rope Grip ‘Q’ Type 3.2mm AISI 316

$1.13 ^{ex. GST}

S260Q-04

Wire Rope Grip ‘Q’ Type 4mm AISI 316

$1.26 ^{ex. GST}

To access Trade Prices, click below TRADE FORM

Wire Rope Grip 'Q' Type AISI 316

Miami Stainless Q Type Wire Rope Grips are made from high quality AISI 316 marine grade stainless steel. Miami Stainless stainless wire rope grips are specifically designed for general purpose and shade sail applications. Wire Rope Grips are also used to secure stainless steel wire rope when the length of the wire rope may need to be shortened or adjusted.

'Q' TYPE GRIPS

CODE	FOR WIRE	THREAD
S260Q-03	3.2mm	M4
S260Q-04	4MM	M5

PRORIG ROPE GRIPS

CODE	FOR WIRE	THREAD	C	H	L	W
S260-02	2mm	M2	8	18	15	13
S260-03	3.2mm	M3	9	21	16	15
S260-04	4mm	M4	10.5	24	19	18
S260-05	5mm	M5	13.2	28	22	20
S260-06	6mm	M6	15	32	28	21
S260-08	8mm	M8	19	41	34	27
S260-10	10mm	M10	23	52	45	34
S260-12	12mm	M12	28	61	50	38
S260-14	14mm	M14	30	67	52	43
S260-16	16mm	M16	34	79	59	47

ECON ROPE GRIPS

CODE	FOR WIRE	THREAD
S260-04	4mm	M4
S260-05	5mm	M5
S260-06	6mm	M6
S260-08	8mm	M8
S260-10	10mm	M10
S260-12	12mm	M12
S260-14	14mm	M12
S260-16	16mm	M13
S260-19	19mm	M14
S260-22	22mm	M16
